WEIPU IP67-Medium WA22 NYLON SERIES WITH THREADED COUPLING

Water tight-IP67
Solder & screw termination
3+PE, 6+PE
CSA certified

WA22 series is a medium size IP67 waterproof connector, specially designed for robust application and requires high water resistance.
1) medium size
2) 3+PE, 6+PE
3) rated current: 16A, 10A
4) gold plating pin
5) IP67 after mated
6) assembly available
7) various connecting arrangements

8) Cable OD range: 4.5-12mm

9) CSA certificated

Applications: This connector is designed with various connecting arrangements. Its strong industrial design enables it to support a lot of harsh and humid environments. It is available in solder and screw termination. WA22 is popular for its compatibility. There are several choices for a multi-choice of cable outer diameter.
