WEIPU IP67 - MINI SF8B METAL SERIES WITH PUSH-PULL LOCKING

Water tight
Dust proof
Quick connection
Brass made

The WEIPU SF8B (SF8) Series is a mini-sized connector made from high-quality brass with chrome plating, specifically designed for applications that demand rapid connections and compact installation spaces. As one of the smallest offerings within the WEIPU SF Series, the SF8B provides excellent performance and versatility.

Key Features:

Miniature Size for Compact Installations
2 to 8 Contact Options
Rated Current: 3A & 5A
Gold-Plated Pins for Enhanced Conductivity
IP67 Waterproof Rating (when mated)
Options for Assembly and Over-Molded Solutions

Applications:

The SF8B Series connectors combine impressive aesthetics with robust functionality. Their elegant brass shells with chrome plating are highly suitable for various demanding environments, including medical devices, beauty and cosmetic equipment, testing and measuring instruments, communication devices, and other precision electronic applications.

Download SF8B Catalogue

SF8B Mating Diagram

Different
connector types

Available in both male and female.
Have options for plug, inline cable connector, panel socket

WEIPU SF series Case- Rail Adapter Design

For the application of rail adapter, ensuring the correct and secure connection is the priority. Thus, it is important to choose a solid, high-quality connector to keep a stable connection. Meanwhile, a connector with a push-pull design can also make it easier to use when switching the mode between plugging and unplugging.
