WEIPU IP67 - MINI SF6B METAL SERIES WITH PUSH-PULL LOCKING

Water tight
Dust proof
Quick connection
Brass made

The WEIPU SF6B (SF6) Series connector is crafted from premium brass with chrome plating, specifically engineered for applications requiring quick connections in highly limited spaces. As the smallest size within the WEIPU SF Series, the SF6B provides exceptional functionality in compact installations.

Key Features:

Miniature Size for Space-Constrained Applications
2 to 5 Contact Options
Rated Current: 3A
Gold-Plated Pins for Superior Conductivity
IP67 Waterproof Rating (when mated)
Assembly and Over-Molded Solutions Available

Applications:

Combining sleek aesthetics with robust performance, the SF6B Series is perfectly suited for precision-driven applications. Its attractive brass shell with chrome plating ensures durability and elegance, making it widely popular in medical instruments, beauty and cosmetic devices, testing and measuring equipment, communication technologies, and various other precise electronic fields.

Download SF6B Catalogue

SF6B Mating Diagram

Different
connector types

Available in both male and female.
Have options for plug, inline cable connector, panel socket

WEIPU SF series Case- Rail Adapter Design

For the application of rail adapter, ensuring the correct and secure connection is the priority. Thus, it is important to choose a solid, high-quality connector to keep a stable connection. Meanwhile, a connector with a push-pull design can also make it easier to use when switching the mode between plugging and unplugging.
