WEIPU IP67 - SMALL SA12 ALUMINIUM SERIES WITH PUSH-PULL LOCKING

Quick connection
Multi-color
Water tight
Dust proof

The WEIPU SA12 Series is a compact anodized aluminum connector specially designed for applications that require fast connection and are easy to grasp. With versatile mounting options, including panel mount, cable mount, and in-line cable mount, the SA12 Series offers the flexibility of cable-to-cable or cable-to-panel connections, with either male or female ends.

Key Feature:

Contact Range: Available with 2-9 contacts, perfect for small to medium connection needs.
Rated Current: Supports 3-13A, ideal for low to medium power applications.
Gold Plated Pins: Provides superior conductivity, enhanced durability, and corrosion resistance.
IP67 Rating: Fully sealed against dust and water ingress when mated, ensuring reliable operation in harsh environments.
Assembly Available: Custom assembly options tailored to specific requirements.
Color Options: Available in Black, Silver, Red, Blue, and Green, offering flexibility in matching the connector to your design.

Applications:

The WEIPU SA12 Series connector is highly popular due to its compact size, high reliability, and versatile design. It is especially favored in applications such as LED lighting, solar applications, controllers, agricultural devices, test and measurement equipment, etc.

Download SA12 Catalogue

SA12 Mating Diagram

Different
connector types

Available in both male and female.
Have options for plug, inline cable connector, panel socket

SA series Case-Outdoor Bird Alert

As the devices are often placed in cold and rough weather, where WEIPU high waterproof metal series-SA realizes a stable connection and ensures its good operation.
